PRODUCT DESCRIPTION
Construction:
- Panel, Cylinder and Disc: High quality plastic.
Description:.
- Disc is fixed to the frame by threaded rod.
- Air flow can be adjusted by regulating the cone up and down(+A or -A).
- Foam gasket is sealed around the back of the frame to avoid the air leakage.
- Disc valves are best suited to air distribution systems handling relatively low air flow rates within small circular duct work. It is recomm-ened for air supplying of small space,exha-ust of greasy and damp air in damp areas such as toilets, bathrooms and kitchens.
- It can be mounted in the wall, ceiling or exposed to air ducts with mounting rings.
Color:
- Any color is available.
- Standard color: white
Size:
|
Item Code |
Neck |
Face |
H |
|
DV-P1-075 |
70 |
120 |
75 |
|
DV-P1-100 |
95 |
150 |
75 |
|
DV-P1-125 |
120 |
170 |
80 |
|
DV-P1-150 |
145 |
200 |
80 |
